GR25

GR25: G-HD0001-1FC-BK

Braided Brake Line Front

Braided Brake Line Front

Colour and fitting options available

Specifications
SKU G-HD0001-1FC-BK
Brand GR25


or 4 payments of $30.00 with Info

In Stock
Please call for in-store purchases


Calculate Shipping


Have your own agent? - $0.00
If this option is elected MetalGear will supply you with parcel information (weight / measurements) and address details for you to organise collection with your preferred shipping agent. When you have completed the freight booking, all relevant documentation and consignment notes will need to be emailed to sales@metalgear.com.au for us to attach to your parcel/s. All shipping costs will be at your expense and the transaction will be processed between you and your shipping agent.


More options at checkout


Description

Goodridge Braided Brake Lines

  • Improves brake feel at the lever
  • These lines are custom and made to order
  • Turnaround within 2 business days from ordering (you wlll be contacted if there are delays)
  • Availability may very, you will be contacted if there are delays
  • Full Make Year Model needed to confirm exact fitment
  • Standard lengths are for standard bar height, please advise if more length is required
  • Please contact for further information

Brake Lines in detail.

Goodridge stainless steel motorcycle brake and clutch line kits feature the finest quality hose, consisting of a PTFE inner and stainless steel braided outer coated in a plastic protective coating in the colour of your choice.

Braided brake line eliminates the spongy feel under extreme braking conditions giving greater braking efficiency as well as providing a superior resistance to abrasion and corrosion.

Goodridge kits not only provide reliability and safety, but also brilliant looks that improve the appearance of any bike. Goodridge prides itself in being able to supply stainless steel hydraulic brake line kits for any make or year of motorcycle, be it British, Japanese, American, German or Italian.

  • Goodridge stainless steel braided brake and clutch lines are 100% ADR APPROVED in every state in territory in the WORLD
  • Meets the requirements of DOT and TUV .Goodridge set the standards, the others followed.
  • We can supply a complete build-a-line program so you have a totally universal brake line program at your fingertips
  • Whether you’re building a custom bike or fitting a set of higher or lower bars this program caters for the lot

Technical Details

High speed, constant rapid gear changes and fast stops put great strains on competition hydraulic systems, where failure can be disastrous. The light weight and extremely flexible PTFE hose strongly resists expansion under high pressure and temperature, and provides consistent brake and clutch pressure giving firmer and more efficient operation without that spongy feeling.

PTFE inner tube is compatible with all brake and clutch fluids with outer cover of corrosion and fire resistant stainless steel.

Temperature range: -73 degrees Celsius to 232 degrees Celsius.

  • Bore size: 3.5mm
  • PTFE wall thickness 1.0mm
  • Braid O/D 6.45
  • Cover wall thickness 0.5m
  • Max W.P. pressure 4250 basic
  • Weight 0.088kg/m
  • Burst Pressure of over 12,000PS1

Part Fits:

HARLEY 1986 FLST 1340 Heritage 80 Brakes Front Brake Lines Front -

HARLEY 1987 FLST 1340 Heritage 80 Brakes Front Brake Lines Front -

HARLEY 1988 FLST 1340 Heritage 80 Brakes Front Brake Lines Front -

HARLEY 1988 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1989 FLST 1340 Heritage 80 Brakes Front Brake Lines Front -

HARLEY 1989 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1990 FLST 1340 Heritage 80 Brakes Front Brake Lines Front -

HARLEY 1990 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1990 FLSTF 1340 Fat Boy 81 Brakes Front Brake Lines Front -

HARLEY 1991 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1991 FLSTF 1340 Fat Boy 81 Brakes Front Brake Lines Front -

HARLEY 1992 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1992 FLSTF 1340 Fat Boy 81 Brakes Front Brake Lines Front -

HARLEY 1993 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1993 FLSTF 1340 Fat Boy 81 Brakes Front Brake Lines Front -

HARLEY 1994 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1994 FLSTF 1340 Fat Boy 81 Brakes Front Brake Lines Front -

HARLEY 1995 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1995 FLSTF 1340 Fat Boy 81 Brakes Front Brake Lines Front -

HARLEY 1996 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1996 FLSTF 1340 Fat Boy 81 Brakes Front Brake Lines Front -

HARLEY 1997 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1997 FLSTF 1340 Fat Boy 81 Brakes Front Brake Lines Front -

HARLEY 1998 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1998 FLSTF 1340 Fat Boy 81 Brakes Front Brake Lines Front -

HARLEY 1999 FLSTC 1340 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 1999 FLSTF 1340 Fat Boy 81 Brakes Front Brake Lines Front -

HARLEY 2000 FLSTC 1450 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 2000 FLSTF 1450 Fat Boy 88 Brakes Front Brake Lines Front -

HARLEY 2001 FLSTC 1450 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 2001 FLSTF 1450 Fat Boy 88 Brakes Front Brake Lines Front -

HARLEY 2002 FLSTC 1450 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 2002 FLSTF 1450 Fat Boy 88 Brakes Front Brake Lines Front -

HARLEY 2003 FLSTC 1450 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 2003 FLSTF 1450 Fat Boy 88 Brakes Front Brake Lines Front -

HARLEY 2007 FLSTC 1584 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 2007 FLSTF 1584 Fat Boy 96 Brakes Front Brake Lines Front -

HARLEY 2008 FLSTC 1584 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 2008 FLSTF 1584 Fat Boy 96 Brakes Front Brake Lines Front -

HARLEY 2009 FLSTC 1584 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 2009 FLSTF 1584 Fat Boy 96 Brakes Front Brake Lines Front -

HARLEY 2010 FLSTC 1584 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 2010 FLSTF 1584 Fat Boy 96 Brakes Front Brake Lines Front -

HARLEY 2011 FLSTC 1584 Heritage Classic Brakes Front Brake Lines Front -

HARLEY 2011 FLSTF 1584 Fat Boy 96 Brakes Front Brake Lines Front -

HARLEY 2012 FLSTF 1690 Fat Boy 103 Brakes Front Brake Lines Front -

HARLEY 2013 FLSTF 1690 Fat Boy 103 Brakes Front Brake Lines Front -
